| Continuous rating Input |
230W |
| Capacity |
Machine screw : M4 - M8 (5/32" - 5/16") |
| |
Standard bolt : M5 - M14 (3/16" - 9/16") |
| |
High tensile bolt : M5 - M10 (3/16" - 3/8") |
| |
Coarse thread (in length) |
| |
: 22 - 90mm (7/8" - 3-1/2") |
| Driving shank (Hex) |
6.35mm (1/4") |
| Impacts per minute (ipm) |
0-3,200 |
| No load speed (rpm) |
0-3,600 |
| Max. fastening torque |
100N.m (885in.lbs) |
| Dimensions |
184 x 67 x 192mm |
| (L x W x H) |
(7-1/4" x 2-5/8" x 7-9/16") |
| Net weight |
0.99kg (2.2lbs) |
| Power supply cord |
2.5m (8.2ft) |
